My 5ft System Journal

Discussion in 'Members Systems' started by WaRn00b, Jul 17, 2011.

  1. WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    Hi all,

    So I finally started with my tank after moving into the new house...

    Had a overflow box built a while back:

    [​IMG]

    Started putting some sponge and my ceramic rings into the sump and test fitted the 300W heater and return pump:

    [​IMG]

    Tank resting on my workbench/old table whilst we were busy welding:

    [​IMG]

    Modified my tank stand so that it can hold the sump inside the cabinet that I'm planing on building around the stand still, added another 2 x 16mm thick round bars:

    [​IMG]

    [​IMG]

    Also made a cover for the sump, it's a piece of hardboard painted with anti-rust (didn't have anything else and was busy painting the stand, so I figured "why not?" :p ), the underside, i.e. sump side, of the cover is covered with one large piece of self adhesive vinyl to avoid water condensation getting absorbed into the wood:

    [​IMG]

    Made sure everything is in place and then PVC-Welded the plumbing into place:

    [​IMG]

    Decided that I'll be keeping my quarantine/breeding tank in the cabinet as I don't have any other place for it, it has it's own canopy and light, which will be running on the same timer as the rest of the tank if and when it has inhabitants:

    [​IMG]

    Everything done and in place:

    [​IMG]

    Still need to get hold of @Altum to enquire about black substrate,need to buy some more 90 degree bends for the return pipe and then I'm going to buy a big piece of hard board to cover the back of the stand so that it doesn't need to be moved again, then the tank can start running and cycling so long.

    Will then be buying my wood to finish the cabinet around the stand. Will also start experimenting with DIY CO2 for this tank once everything is in place and ready.

    Will update as I go along!!

    Advice, comments, criticism welcome! :)

    Last edited by a moderator: Oct 2, 2016
  2. Guest




  3. Gert Combrink

    Gert Combrink

    Joined:
    Sep 14, 2008
    Messages:
    1,786
    Likes Received:
    16
    Location:
    Protea Hights, Brackenfell, Cape Town.
    Everything looks good!
    I would suggest you leave the back open, for wires, condensation etc.
    You can also build your cabinet in a U-shape, that will fit tightly from the front, once pushed into place!

  4. mxz

    mxz

    Joined:
    Mar 10, 2010
    Messages:
    508
    Likes Received:
    35
    Location:
    Cape Town
    Nice setup..

    I'm also in the process of building a cabinet around my stand.

  5. Zoom

    Zoom Retired Moderator

    Joined:
    Apr 13, 2009
    Messages:
    8,469
    Likes Received:
    119
    Location:
    Jhb- Fourways
    NICE!!!!

    Like the QT tank idea next to the sump.

  6. OP
    WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    Thanks for the comments guys!!

    I'm really excited to get everything going.. only thing holding me back now is that I need substrate, haven't phone @Altum yet.. will contact him today, maybe I can get the substrate and start filling the tank in this week still, will update as I go along!! :)

    @Gert Combrink ... now you've got me thinking if I should leave it open or close it. :p

    Last edited by a moderator: Oct 2, 2016
  7. Donny

    Donny

    Joined:
    Jul 14, 2009
    Messages:
    2,282
    Likes Received:
    21
    Location:
    Churchill Estate, Parow
    Looking awesome, very neat.

  8. shihr

    shihr Glosso

    Joined:
    Jul 26, 2010
    Messages:
    1,838
    Likes Received:
    18
    Location:
    JHB
    wow.. Nice job dude.. That gravel nex to ur stand looks like my aquarium gravel.. Hehe

  9. OP
    WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    Haha.. thanks shihr.. :p

    Quick update..

    Finished the return pipe last night.. looks very neat imho.. just a quick question though.. I used 4 90 degree bends on the pipe.. It's quite a bit shorter than the last time, so that should have decreased loss of flow a little right? But will the flow still stay sufficient coz of all the 90 degree bends?

    Pump is a 2700lt/h atman.

    Just a little schematic to show what I mean:

    [​IMG]

    Last edited: Jul 19, 2011
  10. OP
    WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    Would the return pipe setup be okay like this or should it rather be one straight pipe running up to where it enters the tank?

  11. Firefly

    Firefly Pleco

    Joined:
    Jul 3, 2010
    Messages:
    2,333
    Likes Received:
    33
    Location:
    East London
    Tank and stand looks neat and tidy, nice job. Can't answer the pump question though...

  12. OP
    WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    Thanks meneer. :) Will wait for someone to let me know about the pump/piping. :)

    I'll test it out in any case, if it seems to flow less, then I'll revert to a single pipe with minimal bends.. just going to look untidy.

    Cheers,

    M

  13. sarf

    sarf

    Joined:
    Jan 14, 2009
    Messages:
    677
    Likes Received:
    5
    Location:
    Cape town
    Looks good so far..what you plan on keeping in this tank?

  14. Zoom

    Zoom Retired Moderator

    Joined:
    Apr 13, 2009
    Messages:
    8,469
    Likes Received:
    119
    Location:
    Jhb- Fourways
    I don't see why the bends would make any difference. It will lesson the flow slightly, but I don't think to the point where it's noticable. As long as you ensure the distance is as short as possible. The more piping you have the more resistance you have to the pump.

  15. OP
    WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    Update.. so washed round 51kg of substrate and got everything ready..

    Tank is in place and running..

    So much less hassle living in a house on the ground floor now. Washed the substrate in the yard.. also filled the tank using the hosepipe straight from the tap into the house. lol.

    Will upload the pics of everything tomorrow.

    Flow on the return pipe has increased quite a bit due to being shorter.. so the bends are fine!! :)

    Now to let the tank cycle and then to scape it.. :)

    Still need to find plants and fish.. not 100% sure what I want to get yet.

    Pics to follow ASAP.

  16. OP
    WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    So the pics:

    Sump ready for action. :p

    [​IMG]

    Tank busy filling up:

    [​IMG]

    Tank filled up and running:

    [​IMG]


    Pictures aren't doing any justice to the substrate.. amazing stuff I bought from @Altum.. 100% natural, crushed ruby which looks kind of pinkish/reddish when dry and then some black in between.. goes like a dark desert brown.. very fine and under strong light it has a light shimmer to it as well.. think it will contrast well with the plants and rocks. :)

    I underestimated how much surface area my tank has.. there is a total of 51kg in the tank at the moment yet there isn't really enough to slope the substrate too much, unless I build some structures I can fit under the substrate.. not sure.. will think about it some more.

    Still to come.. will be starting with the cabinet style stand cover and hood soon.

    Just a quick question..

    The water seems quite "milky" and the tank has been running for a day and a half now, I have a little in tank 600lt/h running sponge and some old AC.. should I replace the AC with some fresh AC. Or should I buy a few bags of AC and add that to the sump to clear the water up nicely?

    Thanks!! :)

    Last edited by a moderator: Oct 2, 2016
  17. mxz

    mxz

    Joined:
    Mar 10, 2010
    Messages:
    508
    Likes Received:
    35
    Location:
    Cape Town
    Tank is looking good.

    If you want crystal clear water get some Seachem Purigen and add it to the sump. It works.

  18. OP
    WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    Thanks!! Will see if I can get some Seachem Purigen. :)

    Edit: Just read up on Purigen on the Seachem website.. stuff sounds AMAZING!!

    Wonder where I'll be able to get some from.. let me ask @Altum quickly.

    Thanks for the info again.

    Last edited by a moderator: Oct 2, 2016
  19. boebie

    boebie

    Joined:
    Jul 23, 2009
    Messages:
    480
    Likes Received:
    8
    Location:
    Cape Town
    Very neat setup Warnoob! Liking the substrate too.

  20. varachhia001

    varachhia001

    Joined:
    Jan 24, 2011
    Messages:
    73
    Likes Received:
    0
    Location:
    Ridgeway, Johannesburg South
    @ WaRn00b I must say that the tank looks very neat. I am very impressed with it.

    Please post more pics once fully completed. I would love to see how the take looks finally. Mainly I love to see waht you stock inside.

    Good Stuff.

  21. OP
    WaRn00b

    WaRn00b

    Joined:
    Nov 25, 2010
    Messages:
    393
    Likes Received:
    1
    Location:
    Cape Town
    Thanks for the comments!! Excited about the tank as well!!

    I'll be sure to update as I go along..

    Not sure what to do with the substrate sloping though, but I'll play around a bit and see. :)
